Product Description & Specifications
Confirm the complete catalog number and application requirements before ordering. The specifications below reflect the product information available for this listing.
- Manufacturer
- General Electric
- Sub-Category
- Rating Plug
- Series
- Spectra Series
- Frame
- SRPF
- Rated current
- 200
- Max current rating
- 200
- Voltage
- 600V
- Poles
- 3
- Frame Size
- 200
- Amperage Maximum
- 200
- Amperage Minimum
- 200
- Trip Type
- MICROVERSATRIP-PLUS,MICROVERSATRIP-PM
- UPC
- 783164213232
- GTIN
- 00783164213232
Show all specifications (2 more)
- Dimensions
- 1.75" X 3" X 4"
- Weight
- 0.05 lb
Product description & additional details
SRPF250A200
SRPF250A200 is a General Electric 3-pole RMS rating plug designed for use with SF250 breaker frames, rated at 250 Amps and 600 VAC.This rating plug is part of the GE Spectra series and establishes or changes the long-time trip point of compatible circuit breakers such as Spectra, Power Break, and Power Break II. It features a 200 A plug current rating and dimensions of 4 in L x 3 in W x 1-3/4 in H. The plug supports adjustable instantaneous trip ranges from 590 to 2000 A and complies with UL and CSA standards.
- Manufacturer: General Electric
- Part Number: SRPF250A200
- Amperage: 250 A
- Voltage Rating: 600 VAC
- Poles: 3
- Frame Type: SF250
- Plug Current Rating: 200 A
- Dimensions: 4 in L x 3 in W x 1-3/4 in H
- Interrupt Rating: High Interrupting Capacity
- Trip Unit: Adjustable instantaneous trip range 590 to 2000 A
- Certifications: UL Listed (E11592), CSA (LR40350)
Specifications
- Part Number: SRPF250A200
- Manufacturer : General Electric
- Brand : General Electric
- Category : Circuit Breaker
- Item Subcategory : Rating Plug
- Family : Spectra Series
- Type : SRPF
- Voltage : 600
- Amperage : 200
- Poles : 3
- Frame Size : 200
- Amperage Maximum : 200
- Amperage Minimum : 200
- Trip Type : MICROVERSATRIP-PLUS,MICROVERSATRIP-PM
Product Data
- UPC : 783164213232
- GTIN : 00783164213232
- Dimensions : 1.75" X 3" X 4"
- Weight : 0.05 lb
