2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
SLD69300
SLD69300 is a Siemens Sentron molded case circuit breaker designed for low voltage power distribution with a rated current of 300 amperes and 3-pole configuration. This thermal magnetic circuit breaker features an electronic trip unit (ETU) housed in a robust LD frame, delivering reliable protection and operational efficiency in demanding industrial and commercial applications. The breaker meets UL 489 and IEC 60947-2 standards and is suitable for use at 600VAC, 480VAC, and 240VAC systems.
- Rated Current: 300 Amperes
- Number of Poles: 3
- Voltage Rating: 600VAC
- Breaking Capacity: 25kAIC at 600V, 35kAIC at 480V, 65kAIC at 240V
- Frame: SLD600A
- Trip Type: Thermal Magnetic with Electronic Trip Unit
- Wire Range: 3/0AWG - 500KCM (Copper) / 4/0AWG - 500KCM (Aluminum)
- Dimensions: 7.5 inches (W) x 11 inches (H) x 4 inches (D)
- Certifications: UL 489, IEC 60947-2
- Line and Load Side Lugs: TA2J6500
Specifications
- Part Number: SLD69300
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : SLD
- Voltage : 600
- Amperage : 300
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous
- Frame Size : LD Frame
- Protection : Solid State
Product Data
- UPC : 078364321724
- GTIN : 00783643217249
- Country of Origin : Mexico
- Weight : 25
