S33930 - Square D 1200A 600V 3-Pole Circuit Breaker Subfeed Lug Kit Plug-On Mount

S33930

S33930 is a Square D 3-pole circuit breaker subfeed lug kit rated for 1200 Amps and 600 Volts, designed for plug-on mounting in I-Line panelboards.

This subfeed lug kit features a 4-barrel design accommodating 3/0 AWG to 600 kcmil aluminum or copper conductors. It is compatible with LA, LH, LC, LI, LX, LE, MA, and MH frame molded case circuit breakers in I-Line, HCP, HCP-SU, and HCR-U panelboards. The kit is UL Listed and CSA certified, with a plug-on jaw construction for easy installation and reliable connection. It measures 15 inches in length and is constructed with durable aluminum housing.

Key Specifications
• Amperage: 1200A
• Voltage: 600V 50/60 Hz
• Poles: 3
• Mounting Type: Plug-On
• Wire Size Range: 3/0 AWG to 600 kcmil
• Compatible Frames: LA, LH, LC, LI, LX, LE, MA, MH
• Panelboard Compatibility: I-Line, HCP, HCP-SU, HCR-U
• Interrupt Rating: Not specified
• Series/Frame: S Series
• Certifications: UL Listed, CSA Certified
• Length: 15 inches
• Enclosure Material: Aluminum

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: S33930
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Lug Terminal Kit
• Family : I-Line
• Type : PowerPacT P
• Amperage : 1200
• MCM Size : 600
• Barrels : 4
• Metal Type : Aluminum
• Compatible Frames : M, P, R

Product Data

• UPC : 785901231967
• GTIN : 00785901231967
• Country of Origin : United States
• Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
• Weight : 41.8
• Panel Type : Panelboard HCP 85.98 in (2184 mm) 42.01 in (1067 mm)
  Panelboard HCP-SU 85.98 in (2184 mm) 25.98 in (660 mm)
  Panelboard HCR-U 85.98 in (2184 mm) 44.02 in (1118 mm)
• Certification : UL, CSA
• Wire Size : AWG 3/0...600 kcmil
