QOU3201021 - Square D 20A 240V 3 Pole QOU Series Circuit Breaker with Shunt Trip

QOU3201021

QOU3201021 is a 3 pole, 20 amp, 240 volt circuit breaker from Square D's QOU Series featuring a shunt trip for enhanced control.This thermal magnetic molded case circuit breaker provides reliable overcurrent protection with a 10kA interrupt rating at 240 VAC and 5kA at 48 VDC. It is designed for bolt-on mounting and includes a trip-free toggle mechanism for safe operation. The breaker is suitable for AC and DC applications and meets industry certification standards.

• Amperage: 20 Amps
• Voltage: 240 VAC / 48 VDC
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 10 kA at 240 VAC, 5 kA at 48 VDC
• Series/Frame: QOU Series
• Trip Unit: Thermal Magnetic with Shunt Trip
• Toggle Mechanism: Trip-Free
• Certifications: Industry Standard Compliant
• Dimensions: Approx. 3" W x 2.95" D x 4.05" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOU3201021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOU Series
• Type : QOU
• Voltage : 240
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078590151856
• GTIN : 00785901518563
• Country of Origin : Mexico
• Dimensions : 4.05 in (102.87 mm) x 3 in (76.2 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
• Weight : 1.5
• Wire Size : AWG 14...AWG 2 aluminium/copper
