QOU2601021 - Square D 60A 2 Pole 120/240V Miniature Circuit Breaker with Shunt Trip 10kA Interrupt Rating

QOU2601021

QOU2601021 is a Square D miniature circuit breaker designed for reliable circuit protection with a 60 ampere rating and 2 poles.

This QOU series breaker operates at 120/240 volts AC with a 10kA interrupt rating and features a shunt trip for remote tripping capability. It is UL and CSA certified, suitable for thermal magnetic trip applications, and mounts easily in standard panels. The compact size and robust construction make it ideal for residential and light commercial electrical distribution.

• Amperage: 60A
• Voltage Rating: 120/240 VAC
• Number of Poles: 2
• Interrupt Rating: 10kA
• Trip Unit: Thermal Magnetic with Shunt Trip
• Series/Frame: QOU
• Mounting Type: Plug-in
• Certifications: UL, CSA
• Dimensions: 2.25" W x 2.95" D x 4.05" H

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOU2601021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 120/240
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 078590151850
• GTIN : 00785901518501
• Country of Origin : Mexico
• Dimensions : 4.05 in (102.87 mm) x 2.25 in (57.15 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
• Weight : 1.06
• Certification : IEC, UL listed
• Wire Size : AWG 14...AWG 2 aluminium/copper
