Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QOU1401021
QOU1401021 is a 1-pole, 40A molded case circuit breaker from the Square D QOU Series, designed for reliable overcurrent and short-circuit protection in residential and commercial applications. This Square D QOU1401021 circuit breaker features a thermal-magnetic trip unit and is rated for 120/240V AC, making it suitable for a wide range of electrical systems. It offers a high interrupting rating and is UL and CSA certified for safety and performance.
- Part Number: QOU1401021
- Manufacturer: Square D
- Series: QOU
- Amperage: 40A
- Poles: 1
- Voltage: 120/240V AC
- Interrupt Rating: 10kA at 120/240V AC
- Mounting Type: Unit mount
- Trip Unit: Thermal-magnetic
- Certifications: UL, CSA
Specifications
- Part Number: QOU1401021
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QOU Series
- Type : QOU
- Voltage : 120
- Amperage : 40
- Phase : 1
- Poles : 1
- AIC rating : 10kA@120V
- Connection : Bolt-On
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- GTIN : 00785901678571
- Country of Origin : Mexico
- Dimensions : 4.05 in (102.87 mm) x 1.5 in (38.1 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
- Weight : 0.17
- Certification : UL listed - IEC - CSA
- Wire Size : AWG 14...AWG 2 aluminium/copper
