QOU1201021 - Square D 20A 1-Pole Miniature Circuit Breaker, 120/240VAC, 48VDC, 10kA Interrupt, Shunt Trip, QOU Series, Unit Mount

Save $90.52
SKU: QOU1201021-New
Condition: New
Price:
$138.48 $229.00
Stock:
Low inventory, please call for stock check

Same-Day Shipping

Most items ship same-day if ordered by 1:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

QOU1201021 - Square D Bolt-On 20 Amp 1 Pole Circuit Breaker - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
QOU1201021 - Square D Bolt-On 20 Amp 1 Pole Circuit Breaker - Essential Electric Supply

Description

QOU1201021


QOU1201021 is a Square D 1-pole, 20A miniature circuit breaker designed for reliable protection in residential and light commercial applications.

This thermal magnetic circuit breaker features a shunt trip mechanism, unit mounting, and is rated for 120/240VAC and 48VDC. It offers a 10kA interrupt rating at 120/240VAC and 5kA at 48VDC, ensuring robust circuit protection. The QOU series breaker is HACR rated and accepts wire sizes from 14 AWG to 2 AWG.

Key Specifications

  • Amperage: 20A
  • Voltage: 120/240VAC, 48VDC
  • Poles: 1
  • Mounting Type: Unit mount
  • Interrupt Rating: 10kA at 120/240VAC, 5kA at 48VDC
  • Series/Frame: QOU
  • Trip Unit: Thermal magnetic, shunt trip
  • Certifications: HACR rated
  • Wire Size: 14 AWG to 2 AWG
  • Dimensions: 4.05" L x 1.5" W
  • Country of Origin: Mexico
  • Weight: 0.30 kg

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

  • Part Number: QOU1201021
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : QOU Series
  • Type : QOU
  • Voltage : 120/240
  • Amperage : 20
  • Phase : 1
  • Poles : 1
  • AIC rating : 10kA@120V
  • Connection : Unit Mount
  • Functions : Long-Time and Instantaneous Trip
  • Terminal Connection : Slotted Box Lug (Line and Load)
  • Frame Size : 100A/QOU
  • Temp Rating : -13–158 °F (-25–70 °C)
  • MCM Size : Min. Wire Size 14 AWG Max. Wire Size 2 AWG
  • Breaker Type : Shunt Trip
  • Protection : Thermal Magnetic

Product Data

  • UPC : 078590151010
  • GTIN : 00785901510109
  • Country of Origin : Mexico
  • Dimensions : 4.05 in (102.87 mm) x 1.5 in (38.1 mm) x 2.95 in (74.93 mm) (Height x Width x Depth)
  • Weight : 0.66
  • Panel Type : Air Conditioning and Refrigeration Equipment, Heating
  • Standards : CSA, IEC, UL listed
  • Certification : IEC, UL listed
  • Wire Size : AWG 14...AWG 2 aluminium/copper
