QOM90VH - Square D 90A 2 Pole 120/240VAC Bolt-On Circuit Breaker 22kA Interrupt Rating QO Series

QOM90VH

QOM90VH is a Square D 2 pole, 90 amp thermal magnetic circuit breaker designed for 120/240VAC applications with bolt-on mounting.This QO series miniature circuit breaker features a 22kA interrupting rating, thermal magnetic trip unit, and is UL and CSA certified. It is engineered for reliable overcurrent protection in single-phase electrical systems and includes box lugs for secure wiring connections.

• Amperage: 90 Amps
• Voltage: 120/240 VAC
• Number of Poles: 2 Pole
• Mounting Type: Bolt-On
• Interrupting Rating: 22 kAIC
• Series/Frame: QO™ QOM
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, CSA Certified
• Phase: Single Phase
• Includes Box Lugs
• Country of Origin: Mexico

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QOM90VH
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOM Series
• Type : QOM
• Voltage : 240
• Amperage : 90
• Phase : 1
• Poles : 2
• AIC rating : 22kA@240V
• Connection : Bolt-On
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 4 AWG (Cu/Al) Max. Wire Size 2/0 AWG (Cu/Al)
• Breaker Type : Standard
• Protection : Thermal Magnetic

Product Data

• UPC : 785901054733
• GTIN : 00785901054733
• Country of Origin : Mexico
• Dimensions : 5.08 in (129 mm) x 3.5 in (88 mm) x 5 in (127 mm) (Height x Width x Depth)
• Weight : 1.25
• Panel Type : QO Load Center, Homeline Load Center
• Standards : UL Listed, CSA
• Wire Size : AWG 4 to AWG 2/0, Copper/Aluminum
