QOB120HID - Square D 20A 120/240V 1-Pole Miniature Circuit Breaker Bolt-On Mount 10kA Interrupt

QOB120HID

QOB120HID is a Square D 20 Amp, 1 Pole, 120/240 Volt miniature circuit breaker designed for bolt-on mounting with high interrupt capacity.QOB120HID features a thermal magnetic trip unit, 10 kA interrupt rating at 120/240 VAC, and supports wire sizes from 14 to 8 AWG aluminum or copper. It is constructed with fiberglass filled thermoset material and operates at 50/60 Hz frequency. This breaker is suitable for single-phase applications and uses a pressure plate connection type.

• Amperage: 20 A
• Voltage: 120/240 VAC
• Poles: 1
• Mounting Type: Bolt-On
• Interrupt Rating: 10 kA at 120/240 VAC, 5 kA at 48 VDC
• Trip Unit: Thermal Magnetic
• Wire Size: 14 to 8 AWG Al/Cu
• Frequency: 50/60 Hz
• Material: Fiberglass Filled Thermoset
• Connection Type: Pressure Plate
• Dimensions: 0.75 in W x 2.91 in D x 3 in H
• Phase: Single-phase

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product e(more...)

Specifications

• Part Number: QOB120HID
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QOB
• Voltage : 120/240VAC
• Amperage : 20
• Phase : 1
• Poles : 1
• AIC rating : 10kA@120V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Terminal Connection : Pressure Plate
• Frame Size : 100A/QO
• Temp Rating : Minimum Operating Temp 104 Degrees F Max. Operating Temp.104 Degrees F
• MCM Size : Min. Wire Size 14 AWG Max. Wire Size 8 AWG
• Breaker Type : High Intensity Discharge
• Protection : Thermal Magnetic

Product Data

• UPC : 078590154389
• GTIN : 00785901543893
• Country of Origin : Mexico
• Dimensions : 3.0 in (76 mm) x 0.7 in (19 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.28
• Panel Type : Square D NQOD Panelboards
• Standards : CSA, UL Listed
• Certification : UL Listed
