Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QO330SWN
QO330SWN is a 3 pole, 30 amp, 120/240V plug-in neutral switching miniature circuit breaker from Square D, designed for reliable circuit protection in commercial and industrial applications. This QO330SWN breaker features a thermal magnetic trip unit, 10kA interrupting rating, and is part of the QO series, making it compatible with QO load centers. It is engineered for plug-in neutral mounting, providing fast, secure installation and enhanced safety.
- Part Number: QO330SWN
- Manufacturer: Square D
- Amperage: 30A
- Voltage: 120/240V AC
- Poles: 3
- Mounting Type: Plug-In Neutral
- Interrupt Rating: 10kAIC @ 240V
- Series/Frame: QO
- Tripping Mechanism: Thermal Magnetic
- Application: Commercial, Industrial
- Certifications: UL Listed
- Warranty: 18 months
Specifications
- Part Number: QO330SWN
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QO Series
- Type : QO-SW
- Voltage : 240
- Amperage : 30
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 785901400745
- Dimensions : 3.0 in (76 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
- Weight : 0.91
- Wire Size : AWG 14 to AWG 8, Copper/Aluminum
