QO2701021 - Square D 70A 120/240V 2 Pole Plug-In Circuit Breaker, 10kA Interrupt Rating

QO2701021

QO2701021 is a 2 pole, 70 amp, 120/240 Volt plug-in circuit breaker from Square D designed for reliable thermal magnetic protection.This Square D QO2701021 circuit breaker features a 10kA interrupt rating at 240V, common trip thermal magnetic trip unit, and plug-in mounting type. It is suitable for QO load centers and panelboards, providing robust overcurrent protection with a compact design.

• Amperage: 70 Amps
• Voltage: 120/240 VAC, 48 VDC
• Poles: 2 Pole
• Mounting Type: Plug-In
• Interrupt Rating: 10kA @ 240V
• Trip Unit: Thermal Magnetic
• Series/Frame: QO
• Dimensions: Approx. 2.91" L x 2.25" W x 3.12" H
• Common Trip
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QO2701021
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QO Series
• Type : QO
• Voltage : 120/240
• Amperage : 70
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Plug-In
• Functions : Long Time and Instantaneous Trip
• Terminal Connection : Lug
• Frame Size : 100A/QO
• Temp Rating : -13–158 °F (-25–70 °C)
• MCM Size : Min. Wire Size 8 AWG Max. Wire Size 2 AWG
• Breaker Type : Shunt Trip
• Protection : Thermal Magnetic

Product Data

• UPC : 785901494034
• GTIN : 00785901494041
• Country of Origin : Mexico
• Dimensions : 3.1 in (79 mm) x 2.2 in (57 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 1
• Panel Type : QO Load Centers and NQ Panelboards
• Standards : CSA Certified, UL Listed
• Certification : UL Listed
• Wire Size : AWG 8 to AWG 2 Copper/Aluminum
