QO260EPD - Square D 60 Amp 120/240V 2 Pole Ground Fault Circuit Breaker Plug-In QO Series

Save $400.92
SKU: QO260EPD-New
Condition: New
Price:
$311.88 $712.80
Stock:
96 In stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

QO260EPD - Square D Plug-In 60 Amp 2 Pole Circuit Breaker - Essential Electric Supply
QO260EPD - Square D 60 Amp 120/240V 2 Pole Ground Fault Circuit Breaker Plug-In QO Series - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
QO260EPD - Square D Plug-In 60 Amp 2 Pole Circuit Breaker - Essential Electric Supply
QO260EPD - Square D 60 Amp 120/240V 2 Pole Ground Fault Circuit Breaker Plug-In QO Series - Essential Electric Supply

Description

QO260EPD


QO260EPD is a 2 pole, 60 amp ground fault circuit breaker from Square D's QO series designed for 120/240V AC systems.This thermal magnetic circuit breaker features a plug-in mounting type with a 10kA interrupting rating at 120/240VAC. It includes long-time and instantaneous trip functions (LI) for reliable equipment protection and is UL and CSA certified. The breaker supports copper and aluminum wire connections with box lugs and fits QO load centers.
    Key Specifications
    • Amperage: 60 Amps
    • Voltage: 120/240 VAC
    • Poles: 2
    • Mounting Type: Plug-In
    • Interrupting Rating: 10kAIC at 120/240VAC
    • Series/Frame: QO
    • Trip Unit: Thermal Magnetic with LI (Long-Time and Instantaneous)
    • Certifications: UL, CSA
    • Terminal Connection: Box Lugs
    • Wire Gauge: AWG 14-6 Copper, AWG 12-4 Aluminum
    • Circuit Breaker Type: Ground Fault Equipment Protector (GFEP)
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: QO260EPD
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : QO Series
  • Type : QO
  • Voltage : 240
  • Amperage : 60
  • Phase : 1
  • Poles : 2
  • AIC rating : 10kA@240V
  • Connection : Plug-In
  • Functions : LI - Long-Time and Instantaneous Trip
  • Terminal Connection : Lug
  • Frame Size : 100A/QO
  • Temp Rating : -13–158 °F (-25–70 °C)
  • MCM Size : Min. Wire Size 12 AWG (Al), 14 AWG (Cu) Max. Wire Size 4 AWG (Al), 6 AWG (Cu)
  • Breaker Type : Ground Fault Equipment Protection (30mA)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901940807
  • GTIN : 00785901940807
  • Country of Origin : Mexico
  • Dimensions : 4.1 in (105 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
  • Weight : 1
  • Panel Type : QO Load Centers and NQ Panelboards
  • Standards : CSA, UL Listed
  • Certification : UL Listed
  • Wire Size : AWG 14 to AWG 6, Copper, AWG 12 to AWG 4, Aluminum
