QHB225 - Square D 25A 240V 2 Pole Miniature Circuit Breaker Bolt-On 65kA Interrupt

QHB225

QHB225 is a Square D 2 pole miniature circuit breaker rated for 25 amps and 120/240 volts AC with a 65kA interrupt rating and bolt-on mounting.This QHB225 circuit breaker features thermal magnetic trip units providing reliable overcurrent protection and switching for AC systems. It has a quick-make, quick-break toggle mechanism with VisiTrip trip indication for visual trip status. The breaker is HACR rated and UL listed under file E84967 and CSA certified under contract 153555.

• Amperage: 25 Amps
• Voltage: 120/240 VAC
• Poles: 2
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA at 120/240 VAC
• Series/Frame: QO/QHB
• Trip Unit: Thermal Magnetic
• Certifications: UL Listed, CSA Certified
• Toggle with VisiTrip trip indication
• HACR rated for HVAC equipment

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QHB225
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QOB Series
• Type : QHB
• Voltage : 240
• Amperage : 25
• Phase : 1
• Poles : 2
• AIC rating : 65kA@240V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901362326
• GTIN : 00785901362326
• Country of Origin : Mexico
• Dimensions : 3.0 in (76 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
• Weight : 0.61
• Wire Size : AWG 14, AWG 8 Copper or Aluminium
