2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Schneider Electric
- Sub-Category:Molded Case
Description
QH215
QH215 is a Square D 15 Amp, 2 Pole circuit breaker designed for 120/240 VAC applications with a 65 kA interrupt rating and plug-in mounting.This Type QH miniature circuit breaker features a thermal/magnetic trip unit, pressure plate connection for 14 to 8 AWG aluminum or copper wire, and a fiberglass filled thermoset construction. It is rated for 50/60 Hz frequency and operates at a temperature rating of 104 degrees Fahrenheit. The breaker fits NEMA AB1 enclosures and is manufactured by Schneider Electric in Mexico.
- Amperage: 15 A
- Voltage: 120/240 VAC
- Poles: 2
- Interrupt Rating: 65 kA at 120/240 VAC
- Trip Type: Thermal/Magnetic
- Mounting Type: Plug-In
- Wire Size: 14 to 8 AWG Al/Cu
- Enclosure Type: NEMA AB1
- Frequency: 50/60 Hz
- Material: Fiberglass Filled Thermoset
- Temperature Rating: 104°F
- Country of Origin: Mexico
Specifications
- Part Number: QH215
- Manufacturer : Schneider Electric
- Brand : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : QO Series
- Type : QH
- Voltage : 240
- Amperage : 15
- Phase : 1
- Poles : 2
- AIC rating : 65kA@240V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- UPC : 078590101290
- GTIN : 00785901012900
- Country of Origin : Mexico
- Dimensions : 3.0 in (76 mm) x 1.5 in (38 mm) x 2.9 in (74 mm) (Height x Width x Depth)
- Weight : 0.56
