QCR3025H - Cutler Hammer 25A 240V 3-Pole Thermal Magnetic Circuit Breaker DIN Rail Mount

QCR3025H

QCR3025H is a Cutler Hammer 3-pole thermal magnetic circuit breaker rated for 25 amps and 240 volts AC with a 10 kA interrupt rating.This industrial circuit breaker features a fixed terminal design with cable-in/cable-out connections and rear DIN rail mounting. It is part of the QCR series, designed for reliable protection with a thermal-magnetic trip unit (T268). The breaker is UL listed, CSA certified, and HACR rated, suitable for various industrial applications.

• Amperage: 25 A
• Voltage: 240 V AC
• Poles: 3
• Interrupt Rating: 10 kAIC
• Mounting: Rear DIN Rail
• Trip Type: Thermal Magnetic (T268)
• Terminals: Fixed, Cable-in/Cable-out
• Series/Frame: QCR
• Certifications: UL Listed, CSA Certified, HACR Rated
• Product Weight: 0.8 lb
• Dimensions: 5.8 in (L) x 3.6 in (W) x 2.1 in (H)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QCR3025H
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QUICKLAG
• Type : QCR
• Voltage : 240
• Amperage : 25
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 782114225660
• GTIN : 00782114225660
• Country of Origin : Dominican Republic
• Dimensions : 5.8 in x 2.1 in x 3.6 in (Length/Depth x Height x Width)
• Weight : 0.8
• Certification : UL Listed,CSA Certified,HACR Rated
