QCR2060 - Cutler Hammer 60 Amp 240 Volt Two-Pole Thermal Magnetic Circuit Breaker

QCR2060

QCR2060 is a Cutler Hammer two-pole thermal magnetic circuit breaker rated for 60 amps and 120/240 volts.

This Eaton Quicklag Type QCR breaker features a 10 kA interrupt rating, fixed terminals, and cable-in/cable-out connection. It is designed for industrial applications with rear mounting and complies with CSA and UL certifications. The breaker includes thermal and magnetic trip units for reliable overcurrent protection and is HACR rated for HVAC equipment.

Key Specifications
• Amperage Rating: 60 Amp
• Voltage Rating: 120/240 VAC
• Number of Poles: Two-Pole
• Interrupt Rating: 10 kAIC
• Mounting Method: Rear Mount
• Connection Type: Cable-in/Cable-out
• Trip Unit: Thermal Magnetic (T268)
• Terminals: Fixed Box Type Lugs
• Series/Frame: QCR Quicklag
• Certifications: CSA Certified, UL Listed, HACR Rated
• Dimensions: 4.6" x 3.1" x 1.2"
• Weight: 0.25 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QCR2060
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : QUICKLAG
• Type : QCR
• Voltage : 240
• Amperage : 60
• Phase : 1
• Poles : 2
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : LI - Long-Time and Instantaneous
• Protection : Thermal Magnetic

Product Data

• UPC : 786679144466
• GTIN : 00786679144466
• Country of Origin : Dominican Republic
• Dimensions : 4.6 in x 1.2 in x 3.1 in (Length/Depth x Height x Width)
• Weight : 0.25
• Certification : UL Listed,CSA Certified,HACR Rated
