QBL32250 - Square D 3 Pole 250 Amp 240VAC QBL Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, 10kAIC@240V, Unit Mount, UL/CSA/CE/NEMA/NOM/ANCE/IEC/RoHS

Save $988.54
SKU: QBL32250-New
Condition: New
Price:
$823.46 $1,812.00
Stock:
10 In stock, ready to be shipped

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

QBL32250 - Schneider Electric/ Square D Feed-Thru 250 Amp 3 Pole Circuit Breaker - Essential Electric Supply
QBL32250 - Square D 3 Pole 250 Amp 240VAC QBL Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, 10kAIC@240V, Unit Mount, UL/CSA/CE/NEMA/NOM/ANCE/IEC/RoHS - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
QBL32250 - Schneider Electric/ Square D Feed-Thru 250 Amp 3 Pole Circuit Breaker - Essential Electric Supply
QBL32250 - Square D 3 Pole 250 Amp 240VAC QBL Frame Molded Case Circuit Breaker, Thermal Magnetic Trip, 10kAIC@240V, Unit Mount, UL/CSA/CE/NEMA/NOM/ANCE/IEC/RoHS - Essential Electric Supply

Description

QBL32250


QBL32250 is a Square D 3-pole, 250 Amp molded case circuit breaker designed for reliable overcurrent protection in commercial and industrial applications.

This thermal magnetic circuit breaker features a 240VAC voltage rating, 10kAIC interrupting capacity at 240V, and is part of the QBL series with a unit mounting type. It includes long-time and instantaneous trip functions, line and load side lug terminals, and is suitable for feed-thru applications. The QBL32250 is certified to UL, CSA, CE, NEMA, NOM, ANCE, IEC, and RoHS standards, ensuring compliance and safety in diverse electrical environments.

    Key Specifications
  • Part Number: QBL32250
  • Manufacturer: Square D
  • Amperage: 250 Amp
  • Voltage: 240VAC
  • Poles: 3
  • Mounting Type: Unit
  • Interrupt Rating: 10kAIC@240V
  • Series/Frame: QBL
  • Trip Unit: Thermal Magnetic (Long-Time & Instantaneous)
  • Connection: Feed-Thru, Line & Load Side Lug
  • Certifications: UL, CSA, CE, NEMA, NOM, ANCE, IEC, RoHS
  • Temperature Rating: 40 to 70°C (104 to 158°F)

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: QBL32250
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : QBL
  • Voltage : 240
  • Amperage : 250
  • Phase : 3
  • Poles : 3
  • AIC rating : 10kA@240V
  • Connection : Feed-Thru
  • Functions : Long Time and Instantaneous Trip
  • Terminal Connection : Lug
  • Frame Size : Q
  • Temp Rating : -13–158 °F (-25–70 °C)
  • Protection : Thermal Magnetic

Product Data

  • UPC : 785901907237
  • GTIN : 00785901907237
  • Country of Origin : Mexico
  • Dimensions : 6.47 in (164.34 mm) x 4.5 in (114.3 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
  • Weight : 4.74
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
  • Certification : UL, CSA, NOM
