QBL32090 - Square D 90 Amp 240V 3 Pole Powerpact Q Circuit Breaker Thermal Magnetic

QBL32090

QBL32090 is a Square D Powerpact Q series 3 pole molded case circuit breaker rated for 90 amps and 240 volts AC with thermal magnetic protection.This circuit breaker features a 10kA interrupting rating at 240VAC, feed-thru connection type, and includes long-time and instantaneous trip functions. It is designed for unit mounting and has line and load side lug terminals. The breaker meets UL, CSA, NEMA, and NOM certifications and is HACR rated.

• Manufacturer: Square D
• Series: Powerpact Q
• Amperage: 90 Amps
• Voltage: 240 VAC
• Poles: 3
• Interrupting Rating: 10kAIC at 240VAC
• Mounting Type: Unit Mount
• Connection Type: Feed-Thru
• Trip Functions: Long-Time and Instantaneous
• Terminal Connection: Line and Load Side Lug
• Protection Type: Thermal Magnetic
• Certifications: UL, CSA, NEMA, NOM

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: QBL32090
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : QBL
• Voltage : 240
• Amperage : 90
• Phase : 3
• Poles : 3
• AIC rating : 10kA@240V
• Connection : Feed-Thru
• Functions : Long Time and Instantaneous
• Frame Size : Q Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 785901458593
• GTIN : 00785901458593
• Country of Origin : Mexico
• Dimensions : 6.47 in (164.34 mm) x 4.5 in (114.3 mm) x 3.93 in (99.82 mm) (Height x Width x Depth)
• Weight : 4.76
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000
• Certification : UL, CSA, NOM
