PLA34120U44A - Square D PowerPacT P 1200A 3-Pole 480VAC 100kA I-Line Molded Case Circuit Breaker with Micrologic 6.0A Trip Unit

Save $7,734.09
SKU: PLA34120U44A-New
Condition: New
Price:
$19,681.91 $27,416.00
Stock:
1 in stock
Limited availability — we'll confirm stock immediately after your order.

Same-Day Shipping

Most items ship same-day if ordered by 12:30 PM PST.

2 Year Warranty Guaranteed

All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.

Product Questions? Contact Us

Product Info

PLA34120U44A - Square D I-Line Style Plug-In 480V 1200A 3 pole circuit breaker 100kA@480V - Essential Electric Supply
PLA34120U44A - Square D I-Line Style Plug-In 480V 1200A 3 pole circuit breaker 100kA@480V - Essential Electric Supply
PLA34120U44A - Square D PowerPacT P 1200A 3-Pole 480VAC 100kA I-Line Molded Case Circuit Breaker with Micrologic 6.0A Trip Unit - Essential Electric Supply
Roll over image to zoom in Click on image to zoom Images are for reference only
PLA34120U44A - Square D I-Line Style Plug-In 480V 1200A 3 pole circuit breaker 100kA@480V - Essential Electric Supply
PLA34120U44A - Square D I-Line Style Plug-In 480V 1200A 3 pole circuit breaker 100kA@480V - Essential Electric Supply
PLA34120U44A - Square D PowerPacT P 1200A 3-Pole 480VAC 100kA I-Line Molded Case Circuit Breaker with Micrologic 6.0A Trip Unit - Essential Electric Supply

Description

PLA34120U44A


PLA34120U44A is a Square D PowerPacT P series molded case circuit breaker designed for robust electrical protection in commercial and industrial applications.

This electronic trip unit breaker features a 1200A amperage rating, 3-pole design, and 480VAC voltage rating, with an interrupting capacity of 100kA. It utilizes I-Line style plug-in mounting for easy installation and is equipped with a Micrologic 6.0A trip unit for precise overcurrent protection. The breaker is UL 489 listed, CSA and IEC certified, ensuring compliance with international safety standards.

    Key Specifications
  • Amperage: 1200A
  • Voltage: 480VAC (600V max)
  • Poles: 3
  • Mounting Type: I-Line Style Plug-In
  • Interrupt Rating: 100kA
  • Series/Frame: PowerPacT P
  • Trip Unit: Micrologic 6.0A
  • Continuous Current Rating: 80%
  • Certifications: UL 489, CSA, IEC
  • Dimensions: 8.27" W x 8.05" D x 16.16" H
  • Connection: I-Line terminations
  • Environmental: Recyclable packaging, carbon footprint data available

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

  • Part Number: PLA34120U44A
  • Manufacturer : Schneider Electric
  • Brand : Square D
  • Category : Circuit Breaker
  • Item Subcategory : Molded Case
  • Family : Powerpact
  • Type : PLA
  • Voltage : 480
  • Amperage : 1200
  • Phase : 3
  • Poles : 3
  • AIC rating : 100kA@480V
  • Connection : I-Line Style Plug-In
  • Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
  • Temp Rating : -13–158 °F (-25–70 °C)
  • Protection : Solid State

Product Data

  • UPC : 785901455677
  • GTIN : 00785901455677
  • Country of Origin : United States
  • Dimensions : 16.16 in (410.46 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
  • Weight : 32
  • Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
  • Certification : UL, CSA, NOM
  • Wire Size : 4 x AWG 3/0...500 kcmil aluminium/copper

Accesories

Part Manufacture Sub Category
AL1200P7KU
S29450
S33663
