PLA34100 - Square D 1000A 480V 3 Pole I-Line Style Plug-In Circuit Breaker

PLA34100

PLA34100 is a Square D 3 pole circuit breaker rated for 1000 amps and 480 volts with I-Line style plug-in mounting.This molded case circuit breaker features a 100kA interrupting rating at 480V, solid state protection with long-time and instantaneous trip functions, and is designed for use in Powerpact PLA series switchgear. It is UL, CSA, and IEC certified for reliable industrial and commercial applications.

Key Specifications
• Amperage: 1000A
• Voltage Rating: 480V AC
• Poles: 3
• Mounting Type: I-Line Style Plug-In
• Interrupting Rating: 100kA at 480V
• Series/Frame: PLA
• Trip Unit: Solid State (Long-Time and Instantaneous)
• Certifications: UL, CSA, IEC
• Connection Type: I-Line Style Plug-In
• Phase: 3
• Wire Gauge Compatibility: AWG 3/0 to 500 kcmil Aluminum/Copper
• Dimensions (LxWxH): 8.05 x 8.27 x 16.16 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PLA34100
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PLA
• Voltage : 480
• Amperage : 1000
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Frame Size : P Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State

Product Data

• UPC : 060648628611
• GTIN : 03606486286111
• Dimensions : 16.16 in (410.46 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 4 x AWG 3/0...500 kcmil aluminium/copper
