PLA34060U31A - Square D PowerPact P Molded Case Circuit Breaker 600A 600V 3 Pole I-Line Micrologic 3.0 Trip

PLA34060U31A

PLA34060U31A is a Square D PowerPact P molded case circuit breaker designed for industrial power distribution applications.This circuit breaker features a 600 ampere rating, 600 volt voltage rating, and 3 poles with an I-Line plug-in mounting style. It includes a Micrologic 3.0 trip unit with 80% rating and an interrupting rating of 25kA at 600VAC. The breaker is suitable for drawout applications and meets industry certifications for safety and performance.

• Amperage: 600A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: I-Line plug-in
• Interrupt Rating: 25kA at 600VAC
• Series/Frame: PowerPact P
• Trip Unit: Micrologic 3.0, 80% rated
• Connection: Drawout
• Certifications: UL, CSA

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PLA34060U31A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 480
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State

Product Data

• UPC : 762179036616
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
