PLA34060CU33A - Square D PowerPacT P-Frame 600A 480V 3-Pole Molded Case Circuit Breaker

PLA34060CU33A

PLA34060CU33A is a Square D PowerPacT P-Frame molded case circuit breaker designed to protect electrical systems from overloads and short circuits in industrial and commercial applications. PLA34060CU33A features a 600 ampere trip rating with an 800 ampere frame size, three-pole configuration, and 480 volt rating for reliable performance in three-phase power distribution systems. This circuit breaker is part of the PowerPacT P-Frame family, which offers advanced protection capabilities and interchangeable trip unit options for flexible system design.

• Manufacturer: Square D / Schneider Electric
• Catalog Number: PLA34060CU33A
• Frame Size: P-Frame (800 A)
• Trip Rating: 600 Amperes
• Voltage Rating: 480 Volts AC
• Poles: 3
• Product Type: Molded Case Circuit Breaker
• Series: PowerPacT
• Dual Rated: UL 489 and IEC 60947-2

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PLA34060CU33A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PLA
• Voltage : 480
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Frame Size : P Frame
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State

Product Data

• UPC : 3606486119914
• GTIN : 03606486119914
• Country of Origin : United States
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
