PKA36080U31A - Square D 800A 3-Pole 600V I-Line Molded Case Circuit Breaker with Micrologic 3.0 Trip Unit

PKA36080U31A

PKA36080U31A is a Square D molded case circuit breaker designed for high-performance power distribution applications.This 3-pole breaker features an 800 ampere rating and operates at 600 volts AC with a 50kA interrupting capacity at 600VAC. It uses an I-Line style plug-in mounting and includes a Micrologic 3.0 electronic trip unit for precise protection and control. The breaker is UL and CSA certified, suitable for industrial and commercial electrical systems.

• Amperage: 800A
• Voltage Rating: 600 VAC
• Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 50kA at 600 VAC
• Series/Frame: PowerPact P-Frame
• Trip Unit: Micrologic 3.0 Electronic Trip
• Certifications: UL, CSA
• Continuous Current Rating: 80%
• Breaking Capacity: 50kA @ 600VAC
• Dimensions: Approx. 12.86" H x 8.05" W x 8.27" D

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PKA36080U31A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 50kA@480V
• Connection : I-Line Style Plug-In
• Functions : LI - Long-Time and Instantaneous
• Protection : Solid State

Product Data

• UPC : 606486286367
• GTIN : 03606486286364
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
