PJA36040CU44A - Schneider Electric PowerPact P 400A 3 Pole 600VAC 25kA I-Line Circuit Breaker Micrologic 6.0A 100% Continuous

PJA36040CU44A

This 3 pole circuit breaker is rated for 400 amps and 600 volts AC, featuring an interrupting rating of 25kA at 600VAC. It includes a Micrologic 6.0A trip unit and supports 100% continuous current rating. The breaker uses an I-Line style plug-in mounting system and is suitable for three-phase applications.

Key Specifications
• Amperage: 400A
• Voltage Rating: 600VAC
• Poles: 3
• Interrupting Rating: 25kA at 600VAC
• Trip Unit: Micrologic 6.0A
• Continuous Current Rating: 100%
• Mounting Type: I-Line Plug-In
• Series/Frame: PowerPact P
• Phase: 3 Phase

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.




Specifications

• Part Number: PJA36040CU44A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PJA
• Voltage : 600
• Amperage : 400
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Terminal Connection : AL800M23K
• Frame Size : P Frame
• Temp Rating : 13-158 °F (-25-70 °C)
• Protection : Solid State



Product Data

• UPC : 078590189263
• GTIN : 00785901892632
• Country of Origin : United States
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
