PHD36125GN - Eaton Series C 125 A 3-Pole 600 V AC Molded Case Circuit Breaker, Type PHD3, Thermal-Magnetic Trip

PHD36125GN

PHD36125GN is a 3-pole molded case circuit breaker manufactured by Eaton as part of the Series C PHD3 Frame. It provides thermal-magnetic protection for circuits rated up to 125 A and 600 V AC. The PHD36125GN is designed for high-performance applications requiring reliable overload and short-circuit protection in industrial and commercial power distribution systems. This breaker features a fixed trip unit, high interrupting capacity, and a compact design that fits easily into panelboards and switchboards. It is compatible with Eaton’s line of Series C accessories, including auxiliary contacts, shunt trips, and terminal kits.

• Part Number: PHD36125GN
• Manufacturer: Eaton
• Series / Frame: Series C / PHD3 Frame
• Product Type: Molded Case Circuit Breaker (MCCB)
• Poles: 3
• Amperage Rating: 125 A
• Voltage Rating: 600 V AC / 250 V DC
• Trip Unit Type: Thermal-Magnetic (Fixed)
• Interrupting Rating: Up to 65 kA at 480 V AC
• Frame Type: PHD3 Frame (Series C)
• Mounting Type: Bolt-on or panel mount
• Application: Feeder and branch circuit protection for commercial and industrial systems
• Certifications: UL 489 Listed, CSA Certified, IEC 60947-2 Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PHD36125GN
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Bus Plug
• Item Subcategory : Breaker Type
• Family : I-Line
• Type : PHD
• Voltage : 600
• Amperage : 125
• Phase : 3
• AIC rating : 18kA@480V
• Fuse Class : H
• Wire : 4
• Compatible Frames : HDP

Product Data

• UPC : 785901565734
• GTIN : 00785901565734
• Country of Origin : United States
• Dimensions : Height 8.50 in (216 mm) x Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
• Weight : 32.01 lb
• Certification : CSA C22.2 No 27 - UL listed file E22182
