PGF36100U31A - Square D PowerPacT P Frame 1000A 600V 3 Pole Molded Case Circuit Breaker, Electronic Trip, Micrologic 3.0, Bus Bar Mount, UL/CSA

PGF36100U31A

PGF36100U31A is a Square D PowerPacT P Frame molded case circuit breaker designed for high-capacity electrical protection.

This three-pole breaker features a 1000A amperage rating, 600V AC voltage rating, and electronic trip unit with Micrologic 3.0 protection. It is panel-mounted with bus bar connections and is UL and CSA certified for safety and compliance.

Key Specifications
• Part Number: PGF36100U31A
• Manufacturer: Square D
• Series/Frame: PowerPacT P
• Amperage: 1000A
• Voltage: 600V AC
• Poles: 3
• Mounting Type: Panel (bus bar)
• Trip Unit: Electronic, Micrologic 3.0
• Interrupt Rating: 18kA (at 600V AC)
• Certifications: UL, CSA
• Dimensions: 8.27" W x 8.05" D x 16.16" H
• Application: Industrial power distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: PGF36100U31A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Voltage : 600
• Amperage : 1000
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Bolt-On
• Functions : LI - Long-Time and Instantaneous
• Temp Rating : 28-158 °F (-2-70 °C)
• Protection : Solid State

Product Data

• UPC : 785901616771
• GTIN : 785901616771
• Country of Origin : United States
• Dimensions : 16.16 in (410.46 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32.03
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 4 x AWG 3/0...500 kcmil aluminium/copper
