PGA36080U44A - Square D 800A 600VAC 3-Pole PowerPact P Molded Case Circuit Breaker I-Line Plug-In

PGA36080U44A

PGA36080U44A is a Square D 3-pole molded case circuit breaker with an 800 Amp rating and 600VAC voltage capacity designed for PowerPact P frame applications.This circuit breaker features a solid state protection system with LSIG trip functions including long-time, short-time, instantaneous, and ground fault. It has an interrupting rating of 35kAIC at 480VAC and 18kAIC at 600VAC, with an I-Line style plug-in connection and load side lug terminals. Certified to UL, CSA, IEC, CE, NOM, and NEMA standards, it supports wire gauges from 3x AWG 3/0 to 500 kcmil aluminum or copper and operates in temperatures from -25 to 70 °C.

• Amperage: 800A
• Voltage: 600VAC
• Poles: 3
• Series/Frame: PowerPact P (PGA frame)
• Interrupt Rating: 35kA at 480VAC, 18kA at 600VAC
• Mounting Type: I-Line style plug-in
• Trip Unit: LSIG (Long-time, Short-time, Instantaneous, Ground Fault)
• Connection Type: Load side lug
• Certifications: UL, CSA, IEC, CE, NOM, NEMA
• Wire Gauge: 3x AWG 3/0 to 500 kcmil Aluminum/Copper
• Operating Temperature: -25 to 70 °C
• Actuator Type: Toggle

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PGA36080U44A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PGA
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Frame Size : P Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Solid State

Product Data

• UPC : 785901458081
• GTIN : 00785901458081
• Country of Origin : Mexico
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
