PGA36080U31A - Square D 800A 600VAC 3-Pole Molded Case Circuit Breaker PowerPact PGA I-Line Plug-In

PGA36080U31A

PGA36080U31A is a Square D 3-pole molded case circuit breaker with an 800 Amp rating and 600 VAC voltage capacity designed for industrial power distribution.This PowerPact PGA series breaker features a plug-in I-Line mounting style, electronic trip unit, and a high interrupt rating suitable for demanding electrical applications. It supports 3-phase power systems and complies with UL, IEC, and CSA certifications for safety and reliability.

• Amperage: 800 Amps
• Voltage Rating: 600 VAC
• Poles: 3
• Mounting Type: I-Line Plug-In
• Interrupt Rating: 65 kA @ 240 VAC, 35 kA @ 480 VAC, 18 kA @ 600 VAC
• Series/Frame: PowerPact PGA
• Trip Unit: Electronic (Micrologic 3.0 standard)
• Certifications: UL, IEC, CSA Listed
• Dimensions: 12.86" H x 8.27" W x 8.05" D
• Application: Industrial and commercial power distribution

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PGA36080U31A
• Manufacturer : Schneider Electric
• Brand : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Powerpact
• Type : PGA
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : I-Line Style Plug-In
• Functions : Long Time and Instantaneous Trip
• Frame Size : P Frame
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Solid State

Product Data

• UPC : 785901677635
• GTIN : 00785901677635
• Country of Origin : Mexico
• Dimensions : 12.86 in (326.64 mm) x 8.27 in (210.06 mm) x 8.05 in (204.47 mm) (Height x Width x Depth)
• Weight : 32
• Standards : UL, CSA, NEMA, NOM-003-SCFI-2000, IEC 60947-2
• Certification : UL, CSA, NOM
• Wire Size : 3 x AWG 3/0...500 kcmil aluminium/copper
