PDG23P0100B2NJ - Eaton 100 Amp 600 VAC Three Pole Molded Case Circuit Breaker Frame 2 100kA Interrupt Rating

PDG23P0100B2NJ

PDG23P0100B2NJ is a 100 Amp, three pole molded case circuit breaker from Eaton designed for 600 VAC applications.This Eaton Power Defense circuit breaker features a Frame 2 design with a 100 kA interrupting rating at 480 VAC. It includes a PXR10 LSI trip unit providing thermal magnetic protection and is globally rated for reliable performance. The breaker supports standard line and load terminations and complies with RoHS standards.

Key Specifications
• Amperage: 100 A
• Voltage Rating: 600 VAC
• Poles: Three Pole
• Frame: 2
• Interrupt Rating: 100 kA at 480 VAC
• Trip Unit: PXR10 LSI Thermal Magnetic
• Mounting Type: Molded Case
• Global Rating: Yes
• Line and Load Terminations: Standard
• Certifications: RoHS Compliant

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23P0100B2NJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 100
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Feed-Thru
• Functions : LSI - Long-Time, Short-Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679240380
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586
• Certification : UL 489 CCC Marked IEC 60947-2 CSA
