PDG23G0050TFFJ - Cutler Hammer 50A 600VAC 3-Pole Thermal Magnetic Circuit Breaker Frame 2

PDG23G0050TFFJ

PDG23G0050TFFJ is a Cutler Hammer 3-pole thermal magnetic molded case circuit breaker rated for 50 amps and 600VAC operation.

This Power Defense series circuit breaker features a Frame 2 design with a 35kA interrupting rating at 480VAC. It supports 3-phase power, panel mounting, and includes long-time and instantaneous trip functions. The breaker has line and load side lug connections and meets UL, CSA, IEC, CCC, and CE certifications.

Key Specifications
• Amperage: 50A
• Voltage Rating: 600VAC, 250VDC
• Poles: 3
• Frame/Series: Power Defense Frame 2
• Interrupt Rating: 35kAIC at 480VAC
• Mounting Type: Panel Mount
• Trip Unit: Thermal Magnetic with Long-Time and Instantaneous Functions
• Connection Type: Feed-Thru, Line and Load Side Lug
• Certifications: UL, CSA, IEC, CCC, CE
• Phase: 3
• Protection Type: Thermal Magnetic
• Dimensions: Approx. 3.5 x 6 x 4.11 inches

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23G0050TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 50
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679325971
• GTIN : 00786679325971
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.0586
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
