PDG23G0020TFFJ - Cutler Hammer 3 Pole 20A 600VAC Molded Case Circuit Breaker, Frame 2, Thermal Magnetic Trip, 35kA Interrupt Rating

PDG23G0020TFFJ

PDG23G0020TFFJ is a Cutler Hammer (Eaton) 3 pole molded case circuit breaker designed for reliable power distribution protection.

This thermal magnetic circuit breaker features a 20A current rating, 600VAC voltage rating, and is part of the Power Defense PDG2 series with Frame Size 2. It offers both long-time and instantaneous overcurrent protection, with a 35kA interrupt rating at 480VAC. The breaker uses a fixed thermal magnetic trip unit and is suitable for feed-thru mounting applications. Certifications and compliance details should be confirmed with the manufacturer for specific use cases.

Key Specifications
• Part Number: PDG23G0020TFFJ
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 20A
• Voltage: 600VAC
• Poles: 3
• Mounting Type: Feed-Thru
• Interrupt Rating: 35kA at 480VAC
• Series/Frame: Power Defense PDG2, Frame 2
• Trip Unit: Thermal Magnetic (Fixed, Fixed)
• Protection: Long-Time and Instantaneous (LI)
• Connection: Standard line and load lugs
• Class: Class A

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23G0020TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 20
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679249802
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 5.00697937
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
