PDG23G0015TFFJ - Cutler Hammer 15A 600V 3-Pole Power Defense Molded Case Circuit Breaker Frame 2

PDG23G0015TFFJ

PDG23G0015TFFJ is a Cutler Hammer Power Defense molded case circuit breaker designed for reliable protection in electrical distribution systems.This 3-pole circuit breaker features a 15 ampere current rating and a voltage rating of 600 VAC and 250 VDC. It is part of the Power Defense series with a Frame 2 design, offering a 35 kA interrupt rating at 480 VAC, suitable for panel mounting. The breaker uses a thermal magnetic trip unit for dependable overload and short circuit protection and is globally rated for versatile applications.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Amperage: 15 Amps
• Voltage: 600 VAC, 250 VDC
• Poles: 3
• Frame Type: Power Defense Frame 2
• Interrupt Rating: 35 kA at 480 VAC, 18 kA at 600 VAC
• Trip Unit: Thermal Magnetic
• Mounting Type: Panel Mount
• Series: Power Defense (PDG)
• Certifications: Globally Rated

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG23G0015TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 15
• Phase : 3
• Poles : 3
• AIC rating : 35kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679213469
• GTIN : 00786679000000
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 104.6 mm (Length/Depth x Height x Width)
• Weight : 4.95640382
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
