Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG22F0090TFFJ
PDG22F0090TFFJ is a Cutler Hammer 2 pole, 90 amp, 600 volt feed-thru molded case circuit breaker with a 25kA interrupt rating.This circuit breaker features a Frame 2 Power Defense design with fixed thermal and fixed magnetic trip units, standard line and load terminals, and is RoHS compliant. It is rated for 25kA interrupt capacity at 480 VAC and supports a maximum operating voltage of 600 VAC. The breaker uses a feed-thru mounting type for easy panel installation.
- Key Specifications
- Amperage: 90A
- Voltage Rating: 600 VAC max
- Poles: 2
- Mounting Type: Feed-Thru
- Interrupt Rating: 25kA at 480 VAC
- Frame: 2
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Terminals: Standard Line and Load
- Certifications: RoHS Compliant
- Class: Class A
- Product Dimensions: 152.4mm H x 69.9mm W x 88.9mm D
- Weight: 2.041 kg
- Part Number: PDG22F0090TFFJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 90
- Phase : 1
- Poles : 2
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
- UPC : 786679247730
- Dimensions : 88.9 mm x 152.4 mm x 69.9 mm (Length/Depth x Height x Width)
- Weight : 4.55143
