Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG22F0015TFFL
PDG22F0015TFFL is a Cutler Hammer molded case circuit breaker designed for reliable electrical protection.This 2-pole breaker features a 15 ampere rating and a 600 volt AC voltage rating. It is part of Frame 2 with a 25 kA interrupt rating at 480 VAC. The breaker uses fixed thermal and magnetic trip units and is chassis mounted with a lever for easy operation.
- Key Specifications
- Amperage: 15 A
- Voltage Rating: 600 VAC, 250 VDC
- Poles: 2
- Interrupt Rating: 25 kA at 480 VAC
- Frame: 2
- Trip Unit: Fixed Thermal / Fixed Magnetic
- Mounting Type: Chassis Mount
- Connection: Feed-Thru
- Type: Molded Case Circuit Breaker
- Manufacturer: Cutler Hammer (Eaton)
Specifications
- Part Number: PDG22F0015TFFL
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 15
- Phase : 1
- Poles : 2
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679945582
- Dimensions : 9 in x 6.2 in x 4.1 in (Length/Depth x Height x Width)
- Weight : 3.25
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
