Product Info
- Manufacturer:Eaton
- Sub-Category:Molded Case
Description
PDG22F0050TFFJ
PDG22F0050TFFJ is a 2-pole, 50 amp, 600VAC molded case circuit breaker from Eaton's Power Defense series designed for reliable circuit protection.This Eaton PDG22F0050TFFJ breaker features a thermal magnetic trip unit with long-time and instantaneous functions, a 25kA interrupting rating at 480VAC, and feed-thru connection type. It is a Frame 2 breaker suitable for single-phase applications and meets UL, CSA, IEC, and CCC certifications.
- Key Specifications
- Amperage: 50A
- Voltage Rating: 600VAC
- Poles: 2
- Frame Type: PDG Frame 2
- Interrupt Rating: 25kA at 480VAC
- Trip Unit: Thermal Magnetic (LI - Long Time and Instantaneous)
- Connection Type: Feed-Thru
- Phase: 1
- Certifications: UL, CSA, IEC, CCC
- Protection Type: Thermal Magnetic
- Terminal Connection: Standard Line and Load
- RoHS Compliant
Specifications
- Part Number: PDG22F0050TFFJ
- Manufacturer : Eaton
- Brand : Eaton
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Power Defense Series
- Type : PDG
- Voltage : 600
- Amperage : 50
- Phase : 1
- Poles : 11
- AIC rating : 25kA@480V
- Connection : Feed-Thru
- Functions : LI - Long Time and Instantaneous
- Terminal Connection : Standard Line and Load Side Lug
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 786679205624
- GTIN : 00786679205624
- Country of Origin : Dominican Republic
- Dimensions : 88.9 mm x 152.4 mm x 69.9 mm (Length/Depth x Height x Width)
- Weight : 4.55143
- Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
