PDG22F0030TFFJ - Eaton 30A 600V 2-Pole Power Defense Molded Case Circuit Breaker Frame 2 Thermal Magnetic

PDG22F0030TFFJ

PDG22F0030TFFJ is a 2-pole, 30 amp, 600 volt Eaton Power Defense molded case circuit breaker designed for reliable circuit protection.This Eaton PDG22F0030TFFJ breaker features a Frame 2 size with thermal magnetic trip unit providing long-time and instantaneous protection. It has a 25kA interrupting rating at 480VAC and supports feed-thru connection with standard line and load terminals. The breaker is panel mountable and certified to UL, CSA, IEC, CCC, and CE standards, suitable for single-phase applications up to 600VAC or 250VDC.

• Amperage: 30A
• Voltage Rating: 600VAC, 250VDC
• Poles: 2
• Frame Type: Frame 2
• Interrupt Rating: 25kAIC at 480VAC
• Trip Unit: Thermal Magnetic (Long-Time and Instantaneous)
• Mounting Type: Panel Mount
• Connection Type: Feed-Thru
• Phase: 1
• Certifications: UL, CSA, IEC, CCC, CE
• Protection Type: Thermal Magnetic
• Weight: Approximately 4 lbs

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: PDG22F0030TFFJ
• Manufacturer : Eaton
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Power Defense Series
• Type : PDG
• Voltage : 600
• Amperage : 30
• Phase : 1
• Poles : 7
• AIC rating : 25kA@480V
• Connection : Feed-Thru
• Functions : LI - Long Time and Instantaneous
• Terminal Connection : Standard Line and Load Side Lug
• Temp Rating : -13–158 °F (-25–70 °C)
• Protection : Thermal Magnetic

Product Data

• UPC : 786679248539
• GTIN : 00786679248539
• Country of Origin : Dominican Republic
• Dimensions : 88.9 mm x 152.4 mm x 69.9 mm (Length/Depth x Height x Width)
• Weight : 4.55143
• Certification : CCC, CSA, IEC 60947-2, RoHS, UL 489
