Description
P3F363R
P3F363R is a fusible bus plug from Eaton's POW-R-WAY III series, designed for reliable power distribution in industrial and commercial applications. This unit features a 100A current rating and is compatible with 600V busway systems, utilizing Type R fuses for circuit protection. The plug is engineered for three-pole, three-wire configurations and includes a horizontal hanger for secure mounting. With an AIC rating of 200kA at 600V, it provides robust fault current protection. The unit is NEMA compliant and includes a 50% internal ground for added safety. This Eaton POW-R-WAY III fusible bus plug is built for durability and ease of installation, supporting a range of conductor sizes and offering a compact design for efficient space utilization. The clamp and guide mechanism ensures secure connection and alignment during installation.
- Part Number: P3F363R
- Manufacturer: Eaton
- Series: POW-R-WAY III
- Amperage: 100A
- Voltage: 600V
- Poles: 3
- Mounting Type: Horizontal Hanger
- Interrupt Rating: 200kA @ 600V
- Fuse Type: Type R
- Internal Ground: 50%
- Wire Configuration: Three-wire
- Compliance: NEMA
Specifications
- Part Number: P3F363R
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Bus Plug
- Item Subcategory : Fusible
- Family : POW-R-WAY III
- Type : P3F
- Voltage : 600
- Amperage : 100
- Phase : 3
- AIC rating : 200kA@600V
- Fuse Class : R
- Wire : 3
Product Data
- Weight : 45
