Description
P3F321RG
P3F321RG is a three-pole fusible plug-in unit designed for use with Eaton Pow-R-Way III busway systems. This unit provides reliable circuit protection with R class fuses and is rated for 30A at 240V. The Eaton Pow-R-Way III fusible plug-in unit features a robust design for industrial and commercial busway applications. It offers easy plug-in installation and secure grounding with 50% internal ground. The unit is compatible with R class fuses for enhanced protection and is built to meet NEMA standards for durability and safety.
- Part Number: P3F321RG
- Manufacturer: Eaton
- Series: Pow-R-Way III
- Type: Fusible Plug-In Unit
- Number of Poles: Three-pole
- Amperage Rating: 30A
- Voltage Rating: 240V
- Application: Busway
- Fuse Type: R class
- Grounding: 50% Internal
- Compliance: NEMA Compliant
- Certifications: IEEE Certified, ANSI UL 857, CSA Certified
Specifications
- Part Number: P3F321RG
- Manufacturer : Eaton
- Brand : Cutler Hammer
- Category : Bus Plug
- Item Subcategory : Fusible
- Family : POW-R-WAY III
- Type : P3F
- Voltage : 240
- Amperage : 30
- Phase : 3
- AIC rating : 200kA@240V
- Fuse Class : R
- Wire : 3
Product Data
- UPC : 786683021111
- GTIN : 00786683021111
- Country of Origin : United States
- Dimensions : 5.43 in x 22.78 in x 12.36 in (Length/Depth x Height x Width)
- Weight : 22
- Certification : IEEE Certified ANSI UL 857 CSA Certified
