ORPK125A100 - Cutler Hammer 100A Rating Plug Digitrip OPTIM 550 Series C

ORPK125A100

ORPK125A100 is a molded case circuit breaker rating plug designed for use with Eaton Cutler-Hammer Series C breakers. This accessory rating plug is rated for 100 amperes and compatible with 125 ampere frame breakers in Frame K configurations. The ORPK125A100 features Digitrip OPTIM 550 technology and is engineered for use with Series C KD, DK, KDB, HKD, HKDB, KDC, CKD, and CHKD breaker models. The plug measures 2.25 inches in length, 1.5 inches in height, and provides precise current rating adjustment for molded case circuit breaker applications.

• Amperage Rating: 100A
• Frame Size: 125A Frame K
• Trip Unit: Digitrip OPTIM 550
• Series: C
• Compatible Breaker Models: KD, DK, KDB, HKD, HKDB, KDC, CKD, CHKD
• Length: 2.25 inches
• Height: 1.5 inches
• UPC: 782114427064

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: ORPK125A100
• Manufacturer : Cutler Hammer
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Rating Plug
• Family : Series C
• Type : ORPK
• Amperage : 100
• Amperage Maximum : 100
• Amperage Minimum : 100
• Compatible Frames : KD,DK,KDB,HKD,HKDB,KDC,CKD,CHKD
• Trip Type : DIGITRIPOPTIM550,DIGITRIPOPTIM1050

Product Data

• UPC : 782114427064
• GTIN : 00782114427064
• Country of Origin : United States
• Dimensions : 2.25 in x 1.5 in x 1.5 in (Length/Depth x Height x Width)
• Weight : 0.03
• Certification : UL Listed
