Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
NGB3K090B
NGB3K090B is a Siemens 3 pole, 90 amp, 600 volt bolt-on circuit breaker designed for reliable thermal magnetic protection.This Siemens NGB3K090B circuit breaker features a 25kA interrupting rating at 480VAC, NGB frame, and thermal magnetic trip unit with long time and instantaneous trip functions for industrial and commercial applications.
- Manufacturer: Siemens
- Series/Frame: NGB
- Amperage: 90A
- Voltage Rating: 600VAC
- Poles: 3
- Mounting Type: Bolt-On
- Interrupt Rating: 25kA at 480VAC
- Trip Unit: Thermal Magnetic
- Terminal Connection: Load Side Lug
- Certifications: UL489 Listed
Specifications
- Part Number: NGB3K090B
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : VL Series
- Type : NGB
- Voltage : 600
- Amperage : 90
- Phase : 2
- Poles : 3
- AIC rating : 25kA@480V
- Connection : Bolt-On
- Functions : Long Time and Instantaneous Trip
- Temp Rating : -13¡F-158¡F
- Protection : Thermal Magnetic
Product Data
- UPC : 804766339530
- GTIN : 00804766339530
- Country of Origin : Mexico
- Dimensions : 6.701 x 4.5 x 3.799 inch
- Weight : 2.646
- Certification : UL, IEC
- Wire Size : 8 to 1/0 AWS, Cu/Al
