Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
NEL36700LI
NEL36700LI is a Square D Micrologic molded case circuit breaker designed for industrial power distribution applications requiring advanced electronic trip protection. This 3-pole, 700-ampere breaker operates at 600 volts and features a 100kA interrupting capacity at 480 volts, making it suitable for high-demand electrical systems. The unit includes full-function Micrologic electronic trip with Long-Time, Short-Time, Instantaneous, and Ground Fault (LSIG) protection functions, along with an ARP058 installed rating plug and line and load side lug terminals for flexible installation configurations. Built with solid-state electronic technology and rated at 100 percent, this feed-thru style breaker delivers reliable overcurrent and fault protection in demanding industrial environments.
- Part Number: NEL36700LI
- Manufacturer: Square D
- Type: NEL Micrologic
- Poles: 3
- Amperage: 700A
- Voltage: 600V
- Interrupting Capacity: 100kA at 480V
- Trip Functions: LSIG (Long-Time, Short-Time, Instantaneous, Ground Fault)
- Trip Unit: Solid State Electronic Micrologic
- Mounting Style: Feed-Thru
- Rating: 100% Rated
- Terminals: Line and Load Side Lug
Specifications
- Part Number: NEL36700LI
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Micrologic
- Type : NEL
- Voltage : 600
- Amperage : 700
- Phase : 3
- Poles : 3
- AIC rating : 100kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : NE Frame
- Protection : Solid State
Product Data
- Weight : 82
