NDC3800T56W - Eaton 800A 600Vac 3-Pole NG-Frame Series G Electronic Molded Case Circuit Breaker

NDC3800T56W

NDC3800T56W is an Eaton Series C electronic molded case circuit breaker designed for reliable power distribution protection.This NG-frame, Series G breaker features an OPTIM 550 electronic LSIG trip unit, providing precise trip performance. It is a three-pole, 800 ampere breaker rated for 600 Vac operation with a high interrupt rating of 200 kAIC at 240 Vac and 100 kAIC at 480 Vac. The breaker comes without terminals and is HACR rated for HVAC applications.

• Amperage Rating: 800 A
• Voltage Rating: 600 Vac
• Number of Poles: Three-pole
• Frame Type: NG
• Series: Series G
• Trip Unit: OPTIM 550 Electronic LSIG
• Interrupt Rating: 200 kAIC at 240 Vac, 100 kAIC at 480 Vac
• Mounting Type: Complete breaker without terminals
• Frequency: 50/60 Hz
• Compliances: HACR Rated
• Product Dimensions: 8.25 in H x 8.25 in W x 5.5 in D
• Weight: 44 lb

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: NDC3800T56W
• Manufacturer : Eaton
• Brand : Cutler Hammer
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Series C
• Type : NDC
• Voltage : 600
• Amperage : 800
• Phase : 3
• Poles : 3
• AIC rating : 100kA@480V
• Connection : Bolt-On
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Protection : Solid State

Product Data

• UPC : 78211440884
• GTIN : 00782114408841
• Dimensions : 5.5 in x 8.25 in x 8.25 in (Length/Depth x Height x Width)
• Weight : 44
