Product Info
- Manufacturer:Federal Pacific
- Sub-Category:Molded Case
Description
NA20
NA20 is a 1-pole, 20 amp, 120V molded case circuit breaker designed for Federal Pacific load centers with NA frame mounting. This breaker features a plug-on design for easy installation and reliable circuit protection in commercial and industrial applications. The NA20 is a thermal magnetic circuit breaker with long time and instantaneous trip functions. It is built for use in Federal Pacific NA series panels and features load side lug terminals for secure connections. This breaker is UL-listed and CSA-certified for safety and compliance.
- Part Number: NA20
- Manufacturer: Federal Pacific
- Amperage: 20A
- Voltage: 120V AC
- Poles: 1
- Mounting Type: NA Frame
- Series/Frame: NA
- Interrupt Rating: 10kA
- Trip Unit: Thermal Magnetic
- Terminals: Load Side Lug
- Plug-On Design
- UL Listed, CSA Certified
Specifications
- Part Number: NA20
- Manufacturer : Federal Pacific
- Brand : Federal Pacific
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Stab-Lok
- Type : NA
- Voltage : 120
- Amperage : 20
- Phase : 1
- Poles : 1
- AIC rating : 10kA@120V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous
- Protection : Thermal Magnetic
Product Data
- Dimensions : Depth 3.09 in (78.49 mm) x Width 4.44 in (112.78 mm)
- Weight : 0.25
- Certification : CSA
- Wire Size : AWG 14...AWG 2 copper
