Product Info
- Manufacturer:Square D
- Sub-Category:Molded Case
Description
MXF36800G
MXF36800G is a 3-pole, 800 amp, 600 volt molded case circuit breaker from Square D's MX series designed for reliable power distribution protection.This circuit breaker features a solid-state electronic trip unit with long-time, short-time, and instantaneous trip functions. It has an interrupting rating of 25kA at 600V AC (UL/CSA) and 65kA at 240/480V AC, suitable for heavy-duty industrial and commercial applications. The breaker mounts with an I-Line style plug-in connection and is UL, CSA, and IEC certified for safety and performance.
- Key Specifications
- Amperage: 800 A
- Voltage: 600 VAC
- Poles: 3
- Series/Frame: MX
- Mounting Type: I-Line plug-in
- Interrupting Rating: 25kA @ 600V AC (UL/CSA)
- Interrupting Rating: 65kA @ 240/480V AC (IEC)
- Trip Unit: Electronic solid state
- Certifications: UL, CSA, IEC
- Part Number: MXF36800G
- Manufacturer : Square D
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Micrologic
- Type : MXF
- Voltage : 600
- Amperage : 800
- Phase : 3
- Poles : 3
- AIC rating : 65kA@480V
- Connection : Bolt-On
- Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
- Protection : Solid State
- Dimensions : Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
- Weight : 50
Additional Information
This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.
