MXF36600G - Square D PowerPact MXF 600A 3 Pole 600V Molded Case Circuit Breaker Solid State 65kA@480V

MXF36600G

MXF36600G is a Square D PowerPact MXF molded case circuit breaker designed for high-performance electrical protection in commercial and industrial applications. This 3-pole, 600A, 600V circuit breaker features solid state protection and a 65kA interrupting rating at 480V, making it suitable for demanding environments where reliability and safety are critical. The MXF36600G is engineered with a bolt-on mounting style for secure installation and includes advanced trip functions for precise overload and short-circuit protection. The PowerPact MXF series offers robust construction and dependable operation, supporting a wide range of power distribution needs. This breaker is ideal for use in panelboards and switchgear requiring high interrupting capacity and solid state trip technology. Its design ensures compatibility with standard electrical systems and provides long-term durability.

• Part Number: MXF36600G
• Manufacturer: Square D
• Series: PowerPact MXF
• Amperage: 600A
• Voltage: 600V
• Poles: 3
• Mounting Type: Bolt-On
• Interrupt Rating: 65kA@480V
• Protection Type: Solid State
• Frame Type: MXF
• Application: Commercial, Industrial
• Certifications: UL Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: MXF36600G
• Manufacturer : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Micrologic
• Type : MXF
• Voltage : 600
• Amperage : 600
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Protection : Solid State

Product Data

• Dimensions : Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
• Weight : 50
