MXF36500G - Square D Powerpact M-Frame 3 Pole 500A 600V Molded Case Circuit Breaker

MXF36500G

MXF36500G is a Square D Powerpact M-Frame molded case circuit breaker designed for reliable protection in commercial and industrial power distribution systems. This 3-pole, 500A, 600V circuit breaker features a unit mount design and is built for high interrupting capacity applications.Engineered for durability and safety, the MXF36500G offers solid-state electronic trip technology with LI (Long-Time and Instantaneous) trip functions. It is suitable for use in systems requiring robust protection and easy integration into standard panelboards. The breaker is equipped with line and load side lug terminals for secure electrical connections.

• Part Number: MXF36500G
• Manufacturer: Square D
• Series: Powerpact
• Frame: M-Frame
• Poles: 3
• Amperage: 500A
• Voltage: 600V
• Mounting Type: Unit Mount
• Interrupt Rating: 65kA @ 480V
• Connection: Lugs line / Lugs load
• Trip Unit: Electronic, ET 1.0, LI (Long-Time and Instantaneous)
• Certification: UL 489 Listed

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Additional Information

This item does not included Lugs. If you would like lugs please reach out to a sales rep with wiring specs and we can help you with the lugs part number.

Specifications

• Part Number: MXF36500G
• Manufacturer : Square D
• Category : Circuit Breaker
• Item Subcategory : Molded Case
• Family : Micrologic
• Type : MXF
• Voltage : 600
• Amperage : 500
• Phase : 3
• Poles : 3
• AIC rating : 65kA@480V
• Connection : Bolt-On
• Functions : LSIG - Long-Time, Short-Time, Instantaneous and Ground Fault
• Protection : Solid State

Product Data

• Dimensions : Depth 8.05 in (204.47 mm) Width 8.27 in (210.06 mm) Height 12.86 in (326.64 mm)
• Weight : 50
