2 Year Warranty Guaranteed
All items both Re-Certified, and New sold by Essential Electric include a 30 day return policy and a 2-year full warranty. This means that they are guaranteed to be free from defects for a full 2 years from the date that the product was shipped from our warehouse.
Product Questions? Contact Us
Product Info
- Manufacturer:Murray
- Sub-Category:Molded Case
Description
MP230GF
MP230GF is a 30 amp, 2-pole ground fault circuit breaker manufactured by Murray, designed for 120/240 VAC systems with a plug-in mounting type.MP230GF features a 22kA interrupting rating at 240V, thermal magnetic trip unit with long time and instantaneous trip functions, and load side lug terminals. It is UL 489/943 and CSA C22.2 certified, suitable for use in Murray MP frame loadcenters, providing reliable ground fault protection with 5 mA trip sensitivity.
- Key Specifications
- Amperage: 30A
- Voltage: 120/240 VAC
- Poles: 2
- Interrupt Rating: 22kA @ 240V
- Frame Type: MP
- Mounting Type: Plug-In
- Trip Unit: Thermal Magnetic with Ground Fault
- Trip Sensitivity: 5 mA
- Terminal Type: Load Lug
- Wire Size: 14-10 AWG Copper, 12-8 AWG Aluminum
- Certifications: UL 489/943, CSA C22.2
Specifications
- Part Number: MP230GF
- Manufacturer : Murray
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : MP Series
- Type : MP-GT
- Voltage : 240
- Amperage : 30
- Phase : 1
- Poles : 2
- AIC rating : 10kA@240V
- Connection : Plug-In
- Functions : LI - Long-Time and Instantaneous Trip
- Temp Rating : -13–158 °F (-25–70 °C)
- Protection : Thermal Magnetic
Product Data
- UPC : 040892530001
- GTIN : 00040892530001
- Country of Origin : Philippines
- Dimensions : 12.598 x 6.693 x 7.48 inch
- Weight : 1.058
