Product Info
- Manufacturer:Siemens
- Sub-Category:Molded Case
Description
LXD63B500L
LXD63B500L - Siemens Sentron Series molded case circuit breaker rated at 500A, 3-pole, 600V.This Siemens LXD63B500L is a thermal-magnetic molded case circuit breaker from the LD frame (LXD6 series) with standard breaking capacity, designed for reliable overcurrent protection in industrial and commercial applications. It features fixed lugs for secure connections and supports bolt-on mounting.
- Amperage: 500A at 40 Deg C
- Voltage Rating: 600V AC 50/60 Hz, 500V DC
- Poles: 3
- Series/Frame: LD Frame (LXD6)
- Trip Unit: Thermal-Magnetic
- Interrupt Rating: 25kA at 600V, 35kA at 480V
- Mounting Type: Bolt-On
- Type: Molded Case
Specifications
- Part Number: LXD63B500L
- Manufacturer : Siemens
- Brand : Siemens
- Category : Circuit Breaker
- Item Subcategory : Molded Case
- Family : Sentron Series
- Type : LXD
- Voltage : 600
- Amperage : 500
- Phase : 3
- Poles : 3
- AIC rating : 35kA@480V
- Connection : Feed-Thru
- Functions : LI - Long-Time and Instantaneous
- Frame Size : LD Frame
- Temp Rating : -13¡F-158¡F
- Protection : Thermal Magnetic
Product Data
- UPC : 783643011175
- GTIN : 00783643011175
- Country of Origin : Mexico
- Dimensions : 8.661 x 12.992 x 6.707
- Weight : 19.533
- Certification : Ul Listed
