LV431431 - Schneider Electric TM200D Thermal Magnetic Trip Unit 200A 3 Poles for Compact NSX 250 Circuit Breakers

LV431431

LV431431 is a thermal magnetic trip unit designed for Schneider Electric Compact NSX 250 circuit breakers, providing reliable overload and short-circuit protection.This trip unit TM200D features a 200 ampere rating at 40 °C and operates at up to 690 V AC with 3 poles. It offers thermal protection for overload conditions and magnetic protection for short-circuit events, suitable for distribution applications with AC networks at 50/60 Hz.

Key Specifications
• Manufacturer: Schneider Electric
• Part Number: LV431431
• Trip Unit Type: TM200D Thermal Magnetic
• Amperage Rating: 200 A at 40 °C
• Voltage Rating: 690 V AC
• Poles: 3
• Frame Size: 250 (Compact NSX 250)
• Protection: Thermal (overload) and Magnetic (short-circuit)
• Frequency: 50/60 Hz
• Application: Distribution
At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.


Specifications

• Part Number: LV431431
• Manufacturer : Schneider Electric
• Brand : Schneider Electric
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Compact
• Type : LV4
• Voltage : 690
• Poles : 3
• Functions : LI - Long Time and Instantaneous
• Frame Size : 200
• Amperage Maximum : 200
• Amperage Minimum : 200
• Protection : Thermal Magnetic
• Compatible Frames : NS,NSF,NSX,NFNF,NFNL,NFHF,NFHL
• Trip Type : TM-D



Product Data

• GTIN : 03606480018244
• Weight : 1.021
• Standards : UL 508, EN/IEC 60947-2
