LT3500T - Cutler Hammer 500A 600VAC 3-Pole Thermal Magnetic Trip Unit for LT Frame Circuit Breaker

LT3500T

LT3500T is a Cutler Hammer thermal magnetic trip unit designed for LT frame molded case circuit breakers, providing reliable protection with a 500 amp rating.This trip unit features a 3-pole configuration, 600 VAC voltage rating, and is bolt-on mounted. It is UL Listed and CSA Certified, suitable for use in industrial applications requiring a non-interchangeable thermal magnetic trip. The LT3500T fits LT series breakers and offers a 65kA interrupt rating at 480 VAC.

Key Specifications
• Manufacturer: Cutler Hammer (Eaton)
• Part Number: LT3500T
• Amperage: 500 A
• Voltage: 600 VAC
• Poles: 3
• Mounting Type: Bolt-On
• Trip Type: Thermal Magnetic, Non-interchangeable
• Frame/Series: LT Frame, Series C
• Interrupt Rating: 65kA @ 480 VAC
• Certifications: UL Listed, CSA Certified

At Essential Parts, we offer fast shipping, lowest price, and expert support to help you get the right product every time.

Specifications

• Part Number: LT3500T
• Manufacturer : Cutler Hammer
• Brand : Eaton
• Category : Circuit Breaker
• Item Subcategory : Trip Units & Programmers
• Family : Series C
• Type : LT
• Voltage : 600VAC
• Amperage : 500
• Poles : 3
• Functions : Long Time and Instantaneous Trip
• Frame Size : 500
• Temp Rating : -13–158 °F (-25–70 °C)
• Amperage Maximum : 500
• Amperage Minimum : 500
• Protection : Thermal Magnetic
• Compatible Frames : LT

Product Data

• UPC : 786679580073
• GTIN : 00786679580073
• Country of Origin : United States
• Dimensions : 8.5 in x 5.6 in x 5.4 in (Length/Depth x Height x Width)
• Weight : 2.8
• Certification : UL
